Control Power nominal:50-300 VDC / 40-265 VAC
Control Power Input Range:110 to 250 VDC, 100 to 240 VAC at 50/60 Hz
Dimensions:approx. 12 in H x 5 in W x 8 in L
Ground Current Input Frequency:20 to 100 Hz
Insulation Class:Class I
Phase Current Input Conversion:True RMS, 1.04 ms/sample
Weight:approx. 4.5 kg
Communications:non-isolated RS232 port, RS485 port
Differential Switch Time Delay:<200 ms
Event Record Triggers:power fail, alarms, self test, inhibit, trip, waveform capture
Operating Range:-40°C (-40°F) to +60°C (140°F)
Storage Range:-40°C (-40°F) to +80°C (176°F)
The GE 369-HI-0-M-0-0-0 Motor Management Relay is meticulously designed to provide superior protection and monitoring for medium to large motors.
With its advanced inrush current adjustment, cooling rate settings, and acceleration time configurations, this relay ensures optimal motor performance under various operating conditions.
The relay is equipped with a range of protective features including undervoltage auto-restart, reverse power detection, and starter failure protection, which are crucial for maintaining system reliability and extending motor lifespan.
Its robust design allows for operation in extreme temperature environments, from -40°F to +140°F, making it an ideal choice for industrial applications where harsh conditions are common.
The relay’s advanced software, EnerVista 369, facilitates easy configuration and monitoring of motor health through detailed event reports, waveform captures, and startup data logging.
This comprehensive solution helps users minimize maintenance costs and optimize operational uptime, contributing to a more efficient and reliable industrial environment.
